Industrial 1000W cabinet air conditioner used in outdoor cabinets

Cabinet air conditioner is different from the traditional commercial and household air conditioning. With extremely high SEER, moisture condensation active control and other cut-edge technologies, it protects power and electronic equipment by providing precise temperature and humidity control. Since the product design and installation are originated from household air conditioners, it can be widely deployed in telecommunication outdoor base stations, power state outdoor cabinet, outdoor LED screen, where require the temperature level below than 35 degree situation. SANDA provides the DC and AC power input type products according different power input.



Technical  parameters

Product mode	SDCA-010EA	Unit
Dimensions (Include flange)	780*449*200	mm
Dimensions(Without flange)	745*445*175	mm
Weight	40	kg
Mounting method	Embedded
Application temperature	-40-70	℃
Working temperature	-15-55	℃
Input voltage	AC 220V±15%   60Hz
Cooling capacity                   L35/L35	1000	W
Heating	500	W
Power consumption         L35/L35	440	W
Airflow	600	m3/h
IP grade	IP 55
Refrigerant	R134A
Noise	60	dB (A)
Surface treatment	RAL7035

Product Features of Industrial 1000W air conditioner used in outdoor cabinets

* Remote measuring, remote communication, remote control, which can realize multiple automatic protection and comprehensive self-testing function;

* Strict process control and famous brand components to ensure high quality and reliability of this product;

* Fit for harsh condition (T3), R134a refrigerant ;

* Multiple self-protection design , RS485 communication port (MODBUS-RTU protocol);

* LED display, all the settings can changed at the field;

* The heating function is optional;

* Dry contact alarm output, NO/NC optional;

* Anti-theft design, without the protection cover.

Industrial 1000W air conditioner used in outdoor cabinets installation size

Application Fields of Cabinet air conditioner

COMPANY INTRODUCTION

 Zhuzhou Sanda Electron Manufacturing Co.,Ltd is an ISO audited factory since 2004.

Your Advantages with SANDA
1. Factory Area: 2000m3 (Dust-free workshop)
2. Production Line: 5
3. Worker: About 100
4. Developing Engineers: 6
5. Certificates: ISO 9001:2008; CE
6. Patent design
7. 12 years R&D and manufacturing experience
8. ODM and OEM are warmly welcomed
9. Main business line: Peltier air cooler, Industrial dehumidifier; Air conditioner; Protection relay; Digital Meters; Temperature and humidity controller etc.
